Quantum
®
XL-6000
Combination Embroidery
- 32 -
12. Return to the Edit screen with the Pictogram.
13. Touch the Pictogram (center pictogram in Edit column).
14. This screen allows the size of the design to increase
up to 120%, or decrease to 90%, by touching a
specific % Pictogram on screen.
15. Touch the 110% Pictogram.
Note: The change can be viewed on screen.
By touching the minus (-) or plus (+), the design size
can be changed in increments of 1%.
Increase the design size to read 114%.
16. Touch the Pictogram to return to the Edit screen.
17. Touch
Pictogram.
18. To try the Zoom function, Touch the Zoom Pictogram.
Touch the x2, and then touch the design on screen to zoom in on a
selected area. Note that in the Zoom Function Mode the stitches are
converted to “Needle Penetration Dots.” This is highly useful when joining
sections or blocks of designs. Return to the regular-size screen by
pressing the x1.
19. Touch the Pictogram to return to Edit screen.
COMBINING DESIGN WITH LETTERING
1. Touch the Pictogram to introduce a new design to the layout.
2. Touch either Arrow Pictogram, located in upper left/right areas of the
screen. Continue touching the arrow pictogram until the Block Alphabet
is on the screen (blue screen).
