APPENDIX 1: SYMBOLS AND
DESCRIPTION
SYMBOLS CHART
Read maintenance
manual
Anchorage point for 1
person only
Read operation
manual
Add lubricant Crushing hazard-
Please wear work
shoes
Wind speed Chemical burn hazards Choke the wheels Release the brake Wind
Noise level Burn hazards Keep a safe distance
from high
temperatures
Pull out to turn on
Push in to turn off
Hot or high pressure
fluid ejection hazards
Hydraulic oil level - low
position
Hydraulic oil level -
high position
Temperature
Replace with tires of
the same
specifications
Only trained
maintenance
personnel can access
the bulkhead
Electrocution hazards
on platform
Electrocution hazards
on the ground and
platform
Keep a safe distance
from the electric
conductors
Tip-over hazards-Avoid
uneven ground
Tip-over hazards-Avoid
uneven ground
Tip-over hazards-
Never use machine
during strong, gusty
wind
Tip-over hazards-
Never use machine
during strong, gusty
wind
Tip-over hazards-
Never push or pull
objects outside
platform
Tip-over hazards-
Never suspend objects
from platform
Collision hazards-
Never lower platform
without checking for
nearby obstacles
