GTTZ10EJ Operation Manual 1-1 © Nov. 2020
1 MACHINE SPECIFICATIONS
Table 1-1 GTTZ10EJ Specifications
MEASURE
ML10EJ (METRIC) ML340EJ (IMPERIAL)
DIMENSIONAL PARAMETERS
Max platform height
8.3 m 27ft 3in
Max working height
10.3 m 33ft 9.5in
Max horizontal reach 3.3 m 10ft 10in
Overall length(stowed)
2.97 m 9ft 9in
Overall width(stowed)
0.99 m 3ft 3in
Overall height (stowed)
1.99 m 6ft 6in
Wheelbase 1.2 m 3ft 11in
Axle track 0.81 m 2ft 8in
Ground clearance (pothole guard
stowed)
0.06 m 2.36in
Ground clearance (pothole guard
deployed)
0.02 m 0.79in
Tire size (diameter×width / type)
406×127mm / solid 16×5in / solid
Platform dimension (L×W×H)
0.99m×0.7m×1.1m 39×27.5×43in
PERFORMANCE PARAMETERS
Platform rated capacity 200 kg
440 lb
Platform max occupancy (indoor
use)
2 persons
Platform max occupancy (outdoor
use)
1 person
Drive speed (stowed)
0～4 km / h
0～2.5 mph
Drive speed (raised)
0～0.6 km / h
0～0.37 mph
Platform lift time (no load)
32～36 s
Platform lower time (no load)
32～37 s
Gradeability
25%
Max allowable inclination
3° (front-to-back) / 3° (side-to-side)
Turning radius (inside)
0 m 0 ft
Turning radius (outside)
1.55 m 5ft 1in
Turntable tailswing
0 m 0 ft
Turntable slewing angle / continuity
345° / incontinuous
