11
Home Dock
Color-Coded Connections
The color-coded Home Dock makes it simple to connect. Just match the colors
on the cable ends to the colors on the dock to see what goes where.
ANTAUDIO POWER
ANT (Silver)
Connection for
the Indoor/
Outdoor Home
Antenna.
AUDIO (Green)
Connection for
stereo system or
powered speakers.
POWER (Red)
Connection for
Home Power
Adapter.
Rear View
