19
four screws (not included) with a 1/4”
head (e.g., an M3 screw), and that are
suitable for the material onto which
you are affixing the antenna, (e.g.,
wood, metal, etc.). The screws should
be spaced 1-3/8” apart horizontally
and 1-1/8” vertically. Refer to the
template on “Indoor/Outdoor Home
Antenna Template” on page 77.
Once you have found a suitable
location for the antenna, route the
antenna cable to the Home Dock. Be sure you
avoid any obstructions that could crimp, kink,
or twist the cable. Use protective grommets
wherever rough openings are encountered.
If the antenna is installed outdoors, route
the cable from the antenna location to the
interior of the home, working the cable through
the basement, under a window sill, etc., and
make adjustments to take up cable slack as
necessary. Reconnect the antenna to the silver
ANT connector at the rear of the Home Dock.
TIP! If your Indoor/Outdoor Home
Antenna’s cable isn’t long enough, visit www.siriusxm.com/accessories, or your
favorite retailer, and consider a 50 ft. Home Antenna Extension Cable or a
Wireless Home Signal Repeater.
Verify that the antenna is pointed south, and that the antenna’s view of the sky is
not blocked by a tree, a building, a bridge, or anything else. Try various locations
1-3/8 in
1-1/8 in
OUTDOORS
SOUTH
