Flite 3 Pump Components
Casing foot
1
Casing screw
2
Casing screw
2
Casing lid
Battery
3
Battery clamping bracket, nuts & washers
Casing screw
2
Main control PCB assembly
4
Casing base
Casing foot
1
Pump head & motor assembly
Bulkhead connector & back nut
Keypad
5
Inlet
hosetail
6
Sealing cap
Carry handle
Power/charging
socket connector
Charging
socket cap
