Page 2 901-F3M Issue A www.skcltd.com
Specifications
Dimensions ....................................................178mm W x 115mm H x 206mm D
Weight ...........................................................2.24 kg (without battery)
3.56 kg (fitted with P901301 3.2Ah battery)
4.84 kg (fitted with P901302 7Ah battery)
Casing IP rating .............................................IP20
Flow range ....................................................2 - 20 litre/min
Back pressure range -
Flow rate
(litre/min)
Maximum back pressure
(inches of water) (kPa)
2 205 51.0
4 175 43.5
8 125 31.1
12 85 21.1
16 50 12.4
20 15 3.7
Battery ..........................................................12V sealed lead/acid
Storage / operating temperature ....................-5 to +50 °C
Charging temperature ....................................-5 to +45 °C
Relative humidity ...........................................0 to 95 % RH
