Page 26 901-F3M Issue A www.skcltd.com
Flite 3 Pump Replacement Parts
Item Part No. Description Item Part No. Description
1 P901111 Casing feet (pack of 4) 11 P901116 Valve housing (pack of 4)
2 P901110 Casing screws (pack of 10) 12 P901208 Pump head inlet tube (pack of 2)
3 P901301 Battery 12V 3.2Ah lead/acid 13 P901125 Valve plate
3 P901302 Battery 12V 7Ah lead/acid 14 P901130 Clamp & diaphragm assembly
4 P901304 Main control PCB assembly 15 P901122 Pump housing
5 P901305 Keypad 16 P901121 Cam follower
6 P901108 Inlet / outlet hosetail 17 P901115 Encoder assembly
7 P901206 Pump head inlet / outlet 18 P901113 Motor
8 P901126 ‘O’ ring (pack of 4) 19 P901118 Tubing tee
9 P901207 Valve retainer (pack of 4) 20 P901203 Tool kit
10 P901129 Valve diaphragm (pack of 4)
If the required part is not listed, contact SKC customer care on +44 (0) 1258 480188.
Note: Table item numbers correspond to the ringed numbers shown in the figures on pages 24 and 25 of this
manual.
