3. Overview
Components
Item Description Chapter
1 Assembly holes 4.2.1
2 Lubricant reservoir 4.2.2
3 Pump elements 4.3.
4 Pressure regulating valve 4.3.5
5 Conical head nipple 4.3.5
6 Electrical connection 4.5
7 General control unit Operating
CAN bus display instructions
8 Pushbuttons Operating
instructions
9 Inputs and outputs Operating
(CAN bus version) instructions
10 CAN bus plug Operating
instructions
Components
without control
with control
with CAN bus control
Assembly instructions
