Page 17
EN
The rules and empirical values for
"EMC-compliant" cabling must be taken into
consideration.
Warning!
When drilling the assembly holes, you
must be careful of any supply lines or
other units, as well as of other hazards
such as moving parts.
Maintain safety clearances and comply
with local regulations for assembly and
accident prevention.
Warning!
Do not tilt the KFG (S) (C) grease
lubrication pump unit!
The pump units are installed on the machine
using three M8 screws with a minimum length
of
20 mm.
Fastening material to be provided by the
customer:
Hexagon head screws (3x) per
DIN933-M8x....-8.8
Washers (3x) per DIN 125-B8.4-St
Warning!
The torque of the fastening screws
depends on the customer’s installation.
Make sure that torque is adequate
when installing the pump unit!
KFGS
KFG
KFGC
Assembly instructions
