12
Adjustments
Adjustments of B6-doser
1. Turn open the pipe connector of the doser’s lubrication piping outlet.
2. Turn open the locking nut in the upper part of the doser.
3. Adjust the dosage by turning the adjustment screw located above the locking nut.
4. Tighten the locking nut in the upper part of the doser.
5. Tighten the pipe connector of doser’s lubrication piping outlet.
Technical specification
Technical specifications
Tabel 1. Technical specifications for dosers
Quantity Range Unit Description
t -25 … +80 °C Operation temperature
p
max
150 bar Max. operation pressure
w x h x d 15 x 90 x 15
17 x 110 x 17
mm B1-B5 doser dimensions,
B6 doser dimensions
Connections
Inlet, mounting rail
x lubricant (1 pc), header piping inlet, pipe connector Ø 8 mm
Outlet, doser
x lubricant (1 pc), lubrication piping outlet, pipe connector Ø 4 mm or Ø 6 mm
