Technical specification
4 l reservoir 10 l reservoir
Max. output 13 g/min 13 g/min
Reservoir 4 l 10 l
Max. pressure 250 bar / 3626 psi 250 bar / 3626 psi
Operation temperature range -30 °C … +70 °C /
-22
°F … +158 °F
- 30
°C … +70 °C /
-22
°F … +158 °F
Lubrication line connections R 1/4” R 1/4”
Lubricant Up to NLGI 2 Up to NLGI 2
Operating voltage 12/24 VDC 12/24 VDC
Power consumption 150 W 150 W
Protection classification IP65 IP65
Weight, (full reservoir) 16 kg / 44,1 lb 24 kg / 61,7 lb
Height of pump 448 mm / 17,64 ” 688 mm / 27,09”
Width of 230 mm / 9,06 ” 230 mm / 9,06 ”
Depth of pump 235 mm / 9,25 ” 235 mm / 9,25 ”
Material Aluminium Aluminium
Connections
Input
x pressure switch, 2 pcs, closing contact
x or pressure transmitter, 2 pcs, 4–20 mA / 0–250 bar, 2-wire type
Output
x lubricant, 1 or 2 pcs, female thread R 1/4”
