14
Tabel 3. Doser codes
Doser Code
B1-R1/8-ZN-4 11391000
B2-R1/8-ZN-4 11391050
B3-R1/8-ZN-4 11391100
B4-R1/8-ZN-4 11391150
B5-R1/8-ZN-4 11391200
B6-R1/8-ZN-4 11391250
B1-R1/8-ZN-6 11391300
B2-R1/8-ZN-6 11391350
B3-R1/8-ZN-6 11391400
B4-R1/8-ZN-6 11391450
B5-R1/8-ZN-6 11391500
B6-R1/8-ZN-6 11391255
Tabel 4. Symbols of mounting rails
BPLD-XX-YY Abbreviation Description
BP: BP Mounting rail, Base Plate
LD: LD Lubrication system type, LD
XX: 02 2-place mounting rail
: 0202 4-place mounting rail,
2 places for dosers on opposite sides
0303 6-place mounting rail,
3 places for dosers on opposite sides
04 4-place mounting rail
06 6-place mounting rail
08 8-place mounting rail
0808 16-place mounting rail,
8 places for dosers on opposite sides
YY: ZN Mounting rail material,
zinc-coated and yellow-passivated steel
S Mounting rail material,
stainless steel
