Symbols
Tabel 7. The symbols of dosers
SMG-X-Y-zz
Abbreviation Description
SMG: SMG The type of the lubrication system, SafeMobeGrease
X: 2 Number of the lines, dual line
Y: 1 Doser body size 1; 2 outlets
2 Doser body size 2; 4 outlets
4 Doser body size 4; 8 outlets
zz: ZN Doser material,
zinc-coated and yellow-passivated steel
Example:
SMG-2-1-ZN
Lubrication s
y
stem t
yp
e, SafeMobeGrease
Number of lines, 2-line
Doser bod
y
size 1; 2 outlets
Doser material, zinc-coated and
y
ellow-
p
assivated steel
Lubricant outlet:
p
i
p
e connector  6 mm
Spare parts
See SMG-doser spare parts (drawing 461812).
