1. Application
The SKF High Pressure Pump, THHP 300, is
intended for the mounting and dismounting of
pressure joints using the SKF Oil Injection Method.
This includes such applications as couplings, gears,
pulleys, flywheels and SKF OK Couplings; where
the surface pressure is often in the region of
250 N/mm2 (250 MPa, 2500 bar, or 36 260 psi).
The high pressure generated by the THHP 300
should not be used with standard hydraulic
cylinders, jacks and other such equipment, which
generally require 70 N/mm2 (70 MPa, 700 bar,
or 10 150 psi).
2.2 Technical data
Designation SKF THHP 300
Description High pressure pump
Maximum pressure 300 MPa (43 500 psi.)
Volume per stroke 1st Stage 40 cm
3
(2.43 in.
3
) – below 1.6 MPa (232 psi.)
Volume per stroke 2nd Stage 0.5 cm
3
(0.03 in.
3
) – above 1.6 MPa (232 psi.)
Oil reservoir capacity 1.8 litres (110 in.
3
) / 1.6 litres (97.6 in.
3
) (usable)
Weight 7.5 kg (16.5 lb) with full oil reservoir
Pressure gauge 0-300 MPa / (0-43 500psi): Diameter 100 mm (4 in.)
Accuracy 1% of full scale
Hose Length 2 m (78 in.)
Hose connection threads: G1/4 female to pump
M16 male thread with special sealing design to attach to
the quick connection coupling.
Maximum torque for M16 thread 40-50 Nm / (29.5-36.9 ft-lb)
Main dimensions of the Pump
(without hose and gauge)
574 x 130 x 200 mm ( 22.6 x 5.1 x 7.9 in.)
Dimensions of the carrying case 800 x 318 x 380 mm (31.5 x 12.5 x 15.0 in.)
Weight of the pump 7.5 kg (16.5 lb)
Weight of the full carrying case 22 kg (48.5 lb)
2. Description
2.1 General description
The SKF High Pressure Pump THHP 300 consists
of a high-pressure pump with a 0-300MPa
(0-43,500 psi) pressure gauge mounted and
includes a high pressure hose and a quick
connection coupling. A loose quick connection nipple
(THPN 300-1) is supplied and can be attached to
the G1/4 and G3/4 conversion nipples included, to
suit the application.
The design allows oil to be automatically
returned to the reservoir, once the pressure is
released, minimizing the risk of oil leakage to the
environment.
