20
SKF TKTI 21 & 31
Customize allows the user to set the time interval for the automatic calibration. The range
varies from 0, which means Off and 30 to 600 seconds with 1 second increments.
Auto calibration is used to improve image quality and measurement accuracy during use.
Note:
Calibration can be forced manually by pressing the A button at least 5 seconds until a
clicking noise is heard.
• LCD Brightness: The user can select the brightness of LCD display with choices being
20, 40, 60 80 and 100%.
• Trigger: The user can define the function given to the trigger
• Laser (default): The trigger operates the laser
- Spot Temp: Adds and deletes the spot Measurement number 1
- Area Temp: Adds and deletes the Area Measurement number 1
- Save key: The trigger will be used to save images
- IR/CCD: Switches between IR image and digital visual image.
• Video Mode: Select PAL or NTSC video output.
• Standby Time: Select the camera standby time from None, 2, 5, 10 or 15 minutes.
When no button is pressed during the set period of time, the camera will turn the
display off automatically, to extend the battery life. Press any key except the power
key to reactivate the screen. If set to None, the function is disabled.
• AutoOffTime: Select None, 2, 5, 10 or 15 minutes. When no button is pressed
during the set period of time, the camera will switch off automatically to extend the
battery life. If set to None, the function is disabled. When StandbyTime is enabled,
AutoOffTime will start calculating from StandbyTime.
4.2.3.3 System Info
Figure 21 System info
Select Setup->Sys. Info to open the System Information dialog box. The camera model,
the serial number, firmware version and Date of Manufacture are available.
