5. Technical Specifications
Technical data
Designation TKTI 21 TKTI 31
Description SKF Thermal Camera TKTI 21 SKF Thermal Camera TKTI 31
Performance
Thermal detector
(FPA)
160 ™ 120 uncooled
FPA microbolometer
380 ™ 280 uncooled
FPA microbolometer
Display 3.5” colour LCD with LED backlight
11 colour palettes
Thermal or Visual Image
Thermal Sensitivity NETD ≤100 mK (0,10 °C)
@ 23 °C ambient and 30 °C
scene temperature
NETD ≤60 mK (0,06 °C)
@ 23 °C ambient and 30 °C
scene temperature
Field of view (FOV) 25° ™ 19°
Spectral range 8 - 14 microns
Theoretical Spatial
Resolution IFOV
2,77 mrad 1,15 mrad
Measureable Spatial
Resolution IFOV
8,31 mrad 3,46 mrad
Accuracy The greater of ±2 °C or ±2% of reading in °C
Focus Manual, Easy Turn Ring, mininum distance 10 cm (3.9 in.)
Visual camera 1,3 Megapixel digital camera
Laser pointer Built-in class 2 laser
Frame rate and
Image Frequency
9Hz
Measurement
Temperature range:
- Standard Mode –20 °C to +350 °C
(–4 °F to +662 °F)
–20 °C to +180 °C
(–4 °F to +356 °F)
- High Temperature
Mode
N/A 100 °C to 600 °C
(212 °F to 1 112 °F)
Measurement
Modes
Up to 4 movable spots. Up to 3 movable areas and 2 movable
lines (maximum, minimum and average temperatures).
Automatic Temperature difference. Hot and Cold spots.
Visual and audible alarms. Isotherms.
Emissivity
correction
User selectable 0,1 to 1,0 in steps of 0,01 with reflected
and ambient temperature compensation.
Emissivity can be individualy adjusted on each cursor.
Emissivity table of common surfaces built-in.

SKF TKTI 21 Specifications

General

Brand	SKF
Model	TKTI 21
Category	Thermal cameras
Language	English
