The variable loading floor can be partially pulled out over the rear bumper. The
variable loading floor which is pulled out in such a way is solely used as a seat, for
example for changing shoes. When pulling out the variable loading floor, the front
edge (close to the rear seats) is lifted at the same time. Thus, small objects can no
longer fall into the space between the luggage compartment floor and the varia-
ble loading floor.
›
Grasp the rear part of the variable loading floor by the handle, raise it slightly in
the direction of the arrow
1
» Fig. 73 and pull it out over the bumper in the di-
rection of the arrow
2
until it engages in the opening
C
» Fig. 73.
›
To push the variable loading floor back into place, grasp the part of the floor by
the handle, raise it slightly in the direction of the arrow
1
and push it forwards
up to the stop.
CAUTION
Ensure that the raised front edge of the variable loading floor is not damaged.
Dividing the luggage compartment with variable loading floor
Fig. 74
Divide the luggage compartment
The luggage compartment can be divided with the variable loading floor.
›
Grasp the rear part of the floor by the handle, raise it in direction of arrow
1
» Fig. 73 and insert the rear edge in one of the openings
A
» Fig. 74.
The variable loading floor is secured in the openings
A
against movement.
The variable loading floor can be pulled out a little more before dividing the lug-
gage compartment with the variable loading floor » page 84. This enlarges the
space between the rear seats and the separation.
CAUTION
Ensure that the raised front edge of the variable loading floor is not damaged.
Removing and installing the variable loading floor
Fig. 75 Luggage compartment: Fold up variable loading floor
Fig. 76 Luggage compartment: remove variable loading floor
The variable loading floor can be removed and reinstalled, if necessary.
Removing the variable loading floor
›
Grasp the rear part of the floor by the handle, raise it slightly in the direction of
the arrow
1
» Fig. 75 and pull it out over the bumper in the direction of the ar-
row
2
until it engages in the opening
C
» Fig. 76.
›
Fold up the loading floor by moving it in the direction of the arrow
3
» Fig. 75.
›
Press the safety buttons
A
» Fig. 76 and remove the floor.
Installing the variable loading floor
›
Fold up the floor and place it on the carrier rails.
›
Push the floor forwards until it engages in the openings
B
in the carrier
rails » Fig. 76.
£
85
Seats and Stowage
