Carefully press in the vicinity of the openings
C
on the floor until it clicks into
place, if necessary press the safety buttons
A
.
WARNING
Ensure the variable loading floor is attached correctly during installation. If
this is not the case, there is a risk of injury for the occupants.

Fixing set
Fig. 77 Telescopic pole and tensioning strap
The fixing set can be used for dividing the luggage compartment or for securing
the objects which are being transported.
Telescopic pole
›
Insert the holders for the telescopic pole into the left and right openings of the
carrier rails.
›
Press the top part of the holder in the direction of the arrow
1
» Fig. 77 and
simultaneously push in the desired position in the direction of the arrow
2
.
›
Ensure that the holder is correctly locked in place.
Tensioning strap
›
Insert the tensioning strap holders into the opening on the left or right carrier
rail.
›
Press the holder in the direction of the arrow
3
» Fig. 77 and simultaneously
push in the desired position in the direction of the arrow
4
.
›
Ensure that the holder is correctly locked in place.
›
Place the object that is to be secured behind the tensioning strap.
›
Press the button
5
on the top side of the holder and tighten the strap.
WARNING
The objects in the luggage compartment must be firmly secured with the fix-
ing set so that they cannot move freely and uncontrollably and to prevent
damage to objects or injuries to occupants.
Note
■
Do not use the fixing set to secure objects that might damage the fixing set.
■
The tensioning strap can also be fully reeled up by pressing the button
5
» Fig. 77.

Moveable lashing eyes
Fig. 78
Moveable lashing eyes
There are four moveable lashing eyes in the luggage compartment that can, for
example, be used to attach the fixing nets.
›
Press the button
1
» Fig. 78 and push the lashing eye in the desired position
in the direction of the arrow
2
.
›
Fold up the clamp
3
» Fig. 78 and, for example, attach the fixing net.

Net partition (Combi)
ä Introduction
This chapter contains information on the following subjects:
Using the net partition behind the rear seats 87
Using the net partition behind the front seats 87
Removing and installing net partition housing 88
£
