DC Electric Full-size RTs

December 2007 Page 63

Section 2 - Operation Labels

No. Label Pictorial Description

Skyjack Logo

Small Skyjack logo - blue

Tape Blue/White

Skyjack pinstripe

Caution Tape Stripe

Caution stripe

Wheel Specifications

Refer to manual for wheel type, offset, pressure and torque.

Tire Pressure*

Inflate tire to indicated pressure.

*Note: Tire pressure changes with varying units.

Model Number*

Product Identifier

*Model number will vary, may not be as shown.

Right Side
