Page 64 December 2007

DC Electric Full-size RTs

Labels Section 2 - Operation

No. Label Pictorial Description

Tape - Red/Blue/Red

Skyjack pinstripe

Skyjack Logo

Large Skyjack logo - blue and red

“Keep”

Keep clear.

“Clear”

Keep clear.

4x4

Product identifier - 4 wheel drive

Annual Inspection

Ensure that work platform has received annual inspection prior to

operation.

Right Side (Continued)
