lb. kg lb. kg psi kPa psf
kg/m
2
min*
10455 4742 4182 1897 114.4 788.8 160.8 785.1
max*
14135 6412 5654 2565 127.3 877.7 217.5 1061.9
8831E
min*
11325 5137 4530 2055 57.7 397.8 168.8 824.2
Outrigger Pads
max*
15050 6827 6020 2731 76.7 528.8 224.3 1095.1
min*
11355 5151 4542 2060 118.0 813.6 174.7 852.9
max*
14835 6729 5934 2692 129.3 891.5 228.2 1114.3
8841E
min*
12225 5545 4890 2218 62.3 429.5 182.2 889.5
Outrigger Pads
max*
15825 7178 6330 2871 80.6 556.0 235.8 1151.5
60614AA-ANSI
*
**
NOTE:
The LCP or OUP that an individual surface can withstand varies from structure to structure and is generally
determined by the engineer or architect for that particular structure.
min - Total aerial platform weight with no options
max - Aerial platform weight + all options
LCP - Locally Concentrated Pressure
is a measure of how hard the aerial platform presses on the areas in direct
contact with the floor. The floor covering (tile, carpet, etc.) must be able to withstand more that the indicated values
above.
OUP - Overall Uniform Pressure is a measure of the average load the aerial platform imparts on the whole
surface directly underneath it. The structure of the operating surface (beams, etc.) must be able to withstand more
than the indicated values above.
8831E
8841E
MODEL
Total Aerial Platform Load
WHEEL LCP ** OUP **
Total Aerial Platform
Weight
