SJ3220, SJ3226, SJ4720, SJ4726, SJ4732 223198ABA
Floor Loading Pressure (ANSI/CSA) Section 2 – Maintenance Tables and Diagrams
Model
Weights Pressures
MEWP weight
Max weight per
wheel
LCP** OFL**
kg lb kg lb kPa psi kPa psf
3220
min* 1776 3917 445 981 536 78 9.6 201
max* 2184 4817 853 1880 749 109 11.9 248
3220
Powerdeck
min* 1952 4304 445 981 536 78 9.6 201
max* 2315 5104 853 1880 749 109 11.9 248
3226
min* 1900 4190 475 1047 552 80 10.3 215
max* 2127 4690 794 1750 718 104 11.5 241
4726
min* 2511 5537 628 1384 632 92 9.5 198
max* 2965 6537 1161 2560 903 131 14.2 234
4726
ACPP
min* 2703 5960 628 1384 632 92 9.5 198
max* 3111 6860 1161 2560 903 131 14.2 234
4732
min* 2492 5496 623 1374 630 91 9.4 197
max* 2809 6196 1066 2350 856 124 10.6 222
* Min: Minimum MEWP weight (Unloaded platform, no options/attachments)
Max: Maximum MEWP weight (Platform loaded to capacity with options/attachments)
Wheel is the weight that can be experienced on one wheel.
Note: This is more than 25% of the machine weight due to possible weight distribution over the machine and platform
** LCP: Local Concentrated Pressure is a measure of how hard the MEWP presses on the area in direct contact with the oor/tire.
OFL: Overall Floor Load (Pressure) is a measure of the average load the MEWP imparts on the whole surface directly underneath the
chassis. This has been calculated by dividing the MEWP weight by the overall oor area occupied by the MEWP (on wheels).
Note: The oor covering (e.g., tile, carpet, etc.) or the structure (e.g., beams) of the operating surface must
be able to withstand more than the values indicated above
Note: The LCP or OFL that an individual surface can withstand varies from structure to structure and is
generally determined by the engineer or architect for that particular structure
