Skyjack SJ63 AJ+ User Manual

SJ63 AJ+ 213211AAA
91
Maximum platform capacities (evenly distributed) Section 7 – Technical Diagrams and Specications
7.7 Maximum platform capacities (evenly distributed)
7.8 Floor loading pressure
Model
Weights Pressures
MEWP Weight
Max Weight per
Wheel** LCP*** OFL***
kg lb kg lb kPa psi kPa psf
SJ63 AJ+
Min* 10680 23550 3000 6600 792 115 14 292
Max* 11136 24550 5445 12000 1064 154 14.6 304
1958AA
*
Min: Minimum MEWP weight (Unloaded platform, no options/attachments)
Max:
Maximum MEWP weight (Platform loaded to capacity with options/attachments)
**
Wheel Load is the weight that can be experienced on one wheel.
Note: This is more than 25% of the machine weight due to possible weight distribution over the machine and platform.
***
LCP: Local Concentrated Pressure is a measure of how hard the MEWP presses on the area in direct contact with the  oor/tire.
OFL: Overall Floor Load (Pressure) is a measure of the average load the MEWP imparts on the whole surface directly underneath
the chassis. This has been calculated by dividing the MEWP weight by the overall  oor area occupied by the MEWP (on wheels).
Note: The floor covering (e.g., tile, carpet, etc.) or the structure (e.g., beams) of the operating surface must be able to withstand
more than the values indicated above.
NOTE
The LCP or OFL that an individual surface can withstand varies from structure to structure and is
generally determined by the engineer or architect for that particular structure.
SJ63 AJ+
Regular Platform Capacity Derated Platform Capacity*
High-capacity zone
454 kg (1000 lb) 454 kg (1000 lb)
3 persons (maximum
number of personnel)
1 person (maximum
number of personnel)
400 N (manual side force) 200 N (manual side force)
Low-capacity zone
300 kg (660 lb) 272 kg (600 lb)
2 persons (maximum
number of personnel)
1 person (maximum
number of personnel)
400 N (manual side force) 200 N (manual side force)
Wind rating 12.5 m/s (28 mph)
Tilt cutout setting (side-to-side x front-to-back) 5 degrees x 5 degrees
1957AA
*NOTE: Refer to Section 3 for the capacity derate switch operation.
