SJ9233 RT, SJ9243 RT, SJ9253 RT 221491AAA
Specifications Section 7 – Specifications
Model SJ9233 RT SJ9243 RT SJ9253 RT
Weight * 6 463 kg (14 250 lb) 7 338 kg (16 180 lb) 8 254 kg (18 200 lb)
Overall Width 2.30 m (7.55’)
Overall Length
(Platform Retracted)
4.43 m (14.53’)
Overall Length
(Platform Extended - Single)
5.81 m (19.06’)
Overall Length
(Platform Extended - Dual)
7.21 m (23.65’)
Platform Size, Inside
(Platform Retracted)
1.82 m (5.97’) x
4.28 m (14.04’)
1.92 m (6.30') x
4.25 m (13.94’)
1.92 m (6.30’) x
4.25 m (13.94’)
Platform Size Inside
(Platform Extended - Single)
1.82 m (5.97’) x
5.65 m (18.54’)
1.92 m (6.30’) x
5.65 m (18.54’)
1.92 m (6.30’) x
5.65 m (18.54’)
Platform Size Inside
(Platform Extended - Dual)
1.82 m (5.97’) x
7.12 m (23.36’)
1.92 m (6.30’) x
7.12 m (23.36’)
1.92 m (6.30’) x
7.12 m (23.36’)
Height
Working Height 12.06 m (39.57’) 15.11 m (49.57’) 18.15 m (59.55')
Platform Elevated Height 10.06 m (33’) 13.11 m (43’) 16.15 m (53’)
Stowed Height (Railings Down) 1.96 m (6.43’) 2.16 m (7.09’) 2.16 m (7.09')
Stowed Height (Railings Up) 2.77 m (9.09’) 2.96 m (9.71’) 2.96 m (9.71')
Drive Height (Maximum) 10.06 m (33’) 13.11 m (43’) 10.06 m (33')
Standard Operating Times
Raise Time (No Load) 52 s 65 s 77 s
Lower Time (No Load) 34 s 38 s 41 s
Raise Time (Rated Load) 76 s 89 s 101 s
Lower Time (Rated Load) 59 s 63 s 66 s
Chassis
Travel Speed (Lowered Travel
Position)
5.6 km/h (3.5 mph)
Travel Speed (Elevated Travel
Position)
≤ 0.80 km/h (≤ 0.5 mph)
Maximum Gradeability 40% 35%
Tires (Solid Rubber) 33 x 12 x 20
Hydraulic Oil
Type
ATF
Bio Oil
Tank Capacity 87 L (23 gal)
1793AA
* Weights are approximate; refer to MEWP nameplate for specific weight.
7.3 Specifications
