SJ9233 RT, SJ9243 RT, SJ9253 RT 221491AAA
Floor loading pressure Section 7 – Specifications
Model
Weights Pressures
MEWP Weight
Max Weight per
Wheel/Outrigger** LCP*** OFL***
kg lb kg lb kPa psi kPa psf
SJ9233 RT on
Wheels
Min* 6463 14250 1860 4100 857 124 6.1 128
Max* 7710 17000 2630 5800 930 135 7.3 153
SJ9233 RT on
Outrigger Pads
Min* 6463 14250 1860 4100 360 52 6.1 128
Max* 7710 17000 2630 5800 516 74 7.3 153
SJ9243 RT on
Wheels
Min* 7338 16180 1950 4300 853 124 7.0 145
Max* 8246 18180 2585 5700 920 133 7.8 163
SJ9243 RT on
Outrigger Pads
Min* 7338 16180 1950 4300 377 55 7.0 145
Max* 8246 18180 2585 5700 500 73 7.8 163
SJ9253 RT on
Wheels
Min* 8254 18200 2268 5000 867 126 7.8 163
Max* 8936 19700 2790 6150 971 141 8.5 177
SJ9253 RT on
Outrigger Pads
Min* 8254 18200 2268 5000 440 64 7.8 163
Max* 8936 19700 2790 6150 540 78 8.5 177
Min: Minimum MEWP weight (Unloaded platform, no options/attachments)
Max: Maximum MEWP weight (Platform loaded to capacity with options/attachments)
Wheel/Outrigger Load is the weight that can be experienced on one wheel/outrigger.
Note: This is more than 25% of the machine weight due to possible weight distribution over the machine and
LCP: Local Concentrated Pressure is a measure of how hard the MEWP presses on the area in direct contact
with the floor/tire/outrigger.
OFL: Overall Floor Load (Pressure) is a measure of the average load the MEWP imparts on the whole
surface directly underneath the chassis. This has been calculated by dividing the MEWP weight by the
overall floor area occupied by the MEWP (on wheels/outriggers).
Note: The floor covering (e.g., tile, carpet, etc.) or the structure (e.g., beams) of the operating surface must
be able to withstand more than the values indicated above.
Note: The LCP or OFL that an individual surface can withstand varies from structure to structure and is generally
determined by the engineer or architect for that particular structure.
7.6 Floor loading pressure
