30
221491AAA SJ9233 RT, SJ9243 RT, SJ9253 RT
Section 3 – Familiarization General components
FAMILIARIZATION
3.4-10 Propane cylinder (optional
equipment)
1
1
Propane cylinder valve: Turn the valve
clockwise to close the fuel supply. Turn the valve
counterclockwise to open the fuel supply. Refer
to Section 3.1 for the location of the propane
cylinder.
3.4-11 Auto-level system (optional
equipment)
The auto-level system deploys and retracts all four
outriggers at the same time. Use this system to level
the MEWP from the platform.
3.5 General components
3.5-1 AC power socket on the platform
The AC power socket is a source of AC power on the
platform when the plug at the base is connected to a
generator or an external power supply.
3.5-2 Folding-guardrail system
When you fold down this system, it decreases the
height of the fully-lowered MEWP to transport the
MEWP and/or to drive the MEWP through doorways.
Refer to Section 6.8 for the procedure on how to fold
the guardrails.
