SJ9233 RT, SJ9243 RT, SJ9253 RT 221491AAA
Visual and daily maintenance inspections Section 4 – Inspections Before Operation
8
9
8a
8b
6
7
6
Muffler and exhaust
▪
Make sure that the muffler and exhaust
systems are correctly attached with no visible
damage.
7
Engine oil level
▪
Use the dipstick to check the oil level.
▪
The oil level must be between the marks L
(low) and H (high). Add oil if it is necessary.
8
Engine intake air filter
▪
Make sure there are no loose or missing parts.
▪
Make sure there is no visible damage.
▪
Squeeze the lips of the vacuator valve
8a
to
remove the dirt and dust.
▪
Do an inspection of the service indicator on
the air cleaner
8b
. Replace the filter element if
necessary.
9
Belts
▪
Make sure that the belts do not have cracks,
are not frayed, and do not have chunks of
material missing.
