Control lights:
- BATTERY
Switches:
- INTERCOM
- TRIM
- HEAD LIGHT
- POS. LIGHT
- FUEL PUMP
- AVIONICS
- MAGNETO A
- MAGNETO B
- MASTER switch
- socket: 12 V DC/10 A
circuit breaker notations
Controls:
- CHOKE
- VENTILATION - OPEN/CLOSED
- HEATING - OPEN/CLOSED
- EMERGENCY PARACHUTE SYSTEM HANDLE
- STARTER BUTTON
- FUEL COCK
- THROTTLE LEVER
- FLAP LEVER
Labels on canopy lock system:
- outside: - inside: - key lock
Labels on the canopy opening system:
Labels on cockpit tunnel (behind the seats):
- Headphones:
Labels under the seat:
- parking brake:
Labels on aircraft skin:
DO NOT STEP! DO NOT TOUCH!
FUEL 60 L
MIN. 95 OCT.
DO NOT PUSH!
250 kPa
Engine instruments:
- Engine speed
- DYNON EMS
- Oil temperature
- Oil pressure
- Fuel pressure
- Water temperature indic.
- Water press. indic
- Cylinder head temperature
