7.4. Engine
Enigne dates:
4-stroke, 4 cylinder horizontaly opposed, spark ignition engine, single central camshaft push rods - OHV
Liquid cooled cylinder heads
Ram air cooled cylinders
Dry sump forced lubrication
Dual breakerless capacitor discharge ignition
2 constant depression carburetors
Mechanical fuel pump
Electric starter (12V, 0.8W)
Integrated AC generator with external rectier-regulator (12V, 20A DC)
Propeller drive via integrated gearbox with mechanical shock absorber and overload clutch
7.4.1. Throttle lever
The throttle lever is used for changing the engine speed. For easier start of cold engine use the choke. Location of
choke lever depend on the type of used engine, or in the case that the physical capabilities allows it, on the customer
requirements.
Choke lever is installed on the throttle lever. Ping the choke lever up, activate the choke. Then it is possible to start up
the cold engine. While engine runs smoothly, deactivate the choke.
To increase the engine speed, push the throttle lever forward; to reduce the engine speed, p the throttle lever
backward.
Engine type: Rotax 912 ULS
Serial Number: 6 779 494
Handle
Choke
Activate
Deactive
Increase RPM
Decrease RPM
