The whole complex is designed so that both of the aps slides simultaneously, therefore it is impossible that the
slide will be not on an even keel.
Flap eect is compensated by deection of lift-side trim surface. The lef-side trim surface is
automaticaly deected according to actual ap position.
Flap eect is compensated via deection of lift-side trim surface. The lef-side trim surface is automaticaly deected
according to actual ap position.
Operation
The aps control lever is used for opening and retracting aps. If the aps lever is down, aps are retracted. For
moving the aps, unlock the lock lever (situated under the aps lever) by moving ahead and than move aps lever to
selected position. The aps position for takeo is in the middle of the range of the aps lever move. The aps position
for landing is situated on the upper end of the range. For retracting the aps unlock the lock lever (by moving ahead)
and than move the aps lever to selected position.
LANDING
TAKEOFFRETRACTED
Lock lever
Flaps lever
Lock
Unlock
