b) Labeling, operating and controlling
Labels on the instrument panel:
- parachute system: - controlling of the trim: - fl aps:
EMERG. PARACHUTE SYSTEM TRIM
PULL TO RELEASE
Control lights:
BATTERY
Switches:
INTERCOM
TRIM
BEACON
FUEL PUMP
MASTER
switch box: CIRCUIT A
CIRCUIT B
socket: 12 V DC/10 A
circuit breaker notations
Controls:
CHOKE
HEATING - PULL TO OPEN
UNDERCARRIAGE UP, DOWN
COOLING L PULL ON
COOLING R PULL ON
Engine instruments:
- RPM - Fuel pressure - Fuel L, Fuel R - EGT (Exhaust Gas Temp.)
- Manifold pressure - Oil pressure - CHT (Cylinder Head Temp.) - Hobbs meter
- Voltmeter - Oil temperature - Motohours
