Maintenance Manual SL 200 Book 2
Locking hook adjusting and checking1.7.
These operations are available only if the plane is lifted up on stands!!
Check locking of undercarriage:
- Switch on the main master. Retract undercarriage and check operation of locks. Switch off the main master.
- Disassemble the covers of instrument panel. Leave the lever of undercarriage in retracted position.
- Check security of ends of steel cables on lever. Clearances for cables between the end and cylinder support:
- Rear hooks (on sides) without clearance.
- Front hook has a clearance of 1,5-2 mm (0.059-0.079 in).
- In case of any diff erent, set clearances as above.
Check unlocking of undercarriage:
