Skytron Skyboom Ergon Series User Manual

Page 23
ERGON SERVICE • REV0
b. Cantilevered Shelves
Figure 5-16.
Removeequipmentfromshelvestobeadjusted
andloosenthegroundscrewsandthefourbolts
securingtherearoftheshelftotheshelftrack.
Avoidcompletely removing the bolts but loosen
sufciently to allow vertical travel necessary to
facilitate the adjustment.
Looseneachboltsecuringtheshelfsupportblocks
onthesideshelftracks.
Adjust the shelves in accordance with the space
requirement needs necessary to accommodate
theequipmenttobeplacedontheshelves.Once
theadjustmentiscomplete,tightenthefourbolts
rmlyandensurethattheshelfissecured.Tighten
the ground screw and verify that the equipment rail
haslessthan0.1ΩEarthresistance.
Install the equipment on the shelf ensuring that the
equipment is stable and secured as necessary.
Maketherespectivemedicalgas,electricalorA/V
and data connections as needed.
4 BOLTS
2 SUPPORT BLOCK BOLTS
GROUND SCREW
Figure 5-17. Cantilevered Shelves
CAUTION
The maximum equipment weight for
eachCantileveredshelfis70lbs.(31
kg.).Usecautiontoavoidoverloading
whenstackingmorethanonepieceof
equipment onthe shelves. Unstable
equipment may fall off the shelves
during positioning of the carrier. Hold
downstrapsmayberequired.
Removeequipmentfromshelvestobeadjusted
andloosenthefourboltsfoundontheunderside
of the shelf, along with the grounding screw. Avoid
completelyremovingtheboltsbutloosensufciently
to allow vertical travel necessary to facilitate the
adjustment.
Adjust the shelves in accordance with the space
requirement needs necessary to accommodate
theequipmenttobeplacedontheshelves.Once
theadjustmentiscomplete,tightenthefourbolts
rmlyandensurethattheshelfissecured,verify
thattheequipmentrailhaslessthan0.1ΩEarth
resistance.
Install the equipment on the shelf ensuring that the
equipment is stable and secured as necessary.
Maketherespectivemedicalgas,electricalorA/V
and data connections as needed.
