Skytron Skyboom Ergon Series User Manual

Page 25
ERGON SERVICE • REV0
b. Flatscreen Arm Tension Adjustment
Remove the lower end cap from the end of the arm
to gain access to the spring tension screw. The end
capissecuredbyascrewlocatedonthetopside
of the arm. Using an allen wrench, adjust spring
tensionbyturningthespringtensionadjustment
screwclockwisetodecreasetensionandcounter
clockwisetoincreasetension.Thearmshouldhold
its positionthroughout its rangeoftravel (gure
5-19).Theverticaltravelstopcanberemoved,if
applicable,toachieveafullrangeofverticaltravel.
Removetheblockbyremovingtheallenbolt.Install
end caps upon completing the adjustment.
CAUTION
Do not remove the vertical travel stop if
the monitor is not installed. Removing
the stop without the weight of the
monitor will result in damage to the
plumbadjustmentsystem.
VERTICAL TRAVEL STOP
(CAN BE REMOVED TO
MAXIMIZE VERTICAL TRAVEL)
SPRING
TENSION
SCREW
ALLEN
WRENCH
CYLINDER
FRICTION
COLLAR
ALLEN
SCREW
Figure 5-19.
c. Flatscreen Arm Plumb Adjustment
TheVerticalSupportTubeandatscreenmonitor
should be aligned perpendicular to the oor
throughout the range of vertical movement of the
springarm.ChecktheplumboftheVerticalSupport
Tubeandusethefollowingproceduretoadjustif
needed.Refertogure5-20.
Figure 5-20.
1. Remove the end cap from the spring
end of the Spring Arm.
2. Loosenthesetscrewsecuringtheplumb
adjuster.
3. Using an open end wrench, turn the
plumb adjusteruntil the desired adjustmenthas
beenachieved.
PLUMB
ADJUSTER
SET
SCREW
plumb adjuster
