4 TECHNICAL DATA
4.1 Absolute Maximum Ratings
Table 4.1 – Absolute maximum ratings
Parameter Symbol Condition Value Unit
Operating temperature T
O
no dew condensation 0 to +80
◦
C
Storage temperature T
S
no dew condensation -20 to +80
◦
C
Maximum baking temperature T
B
repeated > 1 h 150
◦
C
Supply voltage V
DD
to GND 3.0 to 5.5 V
Max. power consumption P
el
all outputs terminated 310 mW
ESD susceptibility HBM (AEC-Q101) 4 kV
Max. radiant output power Φ
max
short circuit current I
F
= 1000 mA <360 mW
Ambient pressure p — > 10
−11
mbar
4.2 Electrical Data
Table 4.2: General electro-optical characteristics
Parameter Symbol Condition Value Unit
Current consumption I
DD
typical 20 mA
Differential analog output voltage U
sin,cos
apropriate gain settings 1 V
PP
Reference output U
ref
- RS485 Square wave
Integrated channel noise U
RMS
500 kHz bandwidth 450 µV
RMS
Max. bandwidth f
3dB
3 dB cutoff 500 kHz
Central emission wavelength λ
pk
- 850 nm
Radiant output power Φ
e
typical < 45 mW
