4 TECHNICAL DATA
Table 4.14: Definition of distance code alternating
No. absolute position [mm] distance to previous [periods] distance to previous [mm]
0 0 0 0
1 10.00 500 10.00
2 20.02 501 10.02
3 30.00 499 9.98
4 40.04 502 10.04
5 50.00 498 9.96
6 60.06 503 10.06
7 70.00 497 9.94
8 80.08 504 10.08
and so on
The figures and tables in this section give the exact definition for coded scales that can be pur-
chased at SmarAct Metrology GmbH & Co. KG. Please notice, that these definition are not ME-
TIRIO specific. From the encoder’s point of view the readhead detects only a single reference
mark at a time. The evaluation algorithm to interpret the codes has to be implemented on the
motion controller.
