Smart-G SSB10 - Pipework and Connections

Gas
Pipe Connection
① Heating water Outlet
② Heating water Return
③ Hot water Outlet
④ Gas Inlet
⑤ Cold water Inlet
- Install butterfly valve for each valve
- Open the every distribution point such as
Water Pipe, Gas Pipe etc to protect freezing
in cold weather during away from home for
long period
- Do not cut off Gas and Electricity
Pipework
19
