Smart-G SSB10 - Air Supply and Exhaust Installation; Installation Location and Opening Area

Tube Size (mm)
Outer Diameter
of Tube
Through Wall
Size (mm)
60(75)
100
Over 100
Warning! Use only the tube that satisfies the specifications.
If the diameter of tube doesn’t fit, exhaust gas can leak and cause carbon monoxide
poisoning.
Manufacturer
Model
Tube Size
Form Authentication
Institution
Samsung Flexible Co.,
Ltd.
SSB-10, SSB-13
SSB-16, SSB-2o
SSB-25,
60(mm)
Korea Gas Safety
Corporation
Korea Energy
Appliances Industry
Association
SSB-30, SSB-35
SSB-40
75(mm)
Warning! Do not connect the exhaust tube of the FF-type boiler to an existing
chimney or exhaust pipes of an apartment. It may cause incomplete
combustion..
Caution
Caution
Caution
Air Supply/Exhaust Tube Installation
■Diameter of air supply/exhaust tube
■Exclusive FF Air Supply/Exhaust Tube for Super Boiler
Forced Airing system: FF Style
※Installation of Exclusive Boiler
 An exclusive boiler room is an exclusive space separated from the spaces for other purposes.
Securing exclusive air inlet/outlet and ventilating opening at the top are required.
 The air inlet/outlet and ventilating opening at the top must be made in a place that prevents
the exhaust gas from escaping the top of the exhaust tube. This includes outdoor spaces or
well-ventilated aisles.
 The effective area of air inlet/outlet or ventilating opening at the top must be bigger than the
cross section of the exhaust tube.
Opening Area of Air Inlet/Outlet and Ventilating Opening at the Top (cm2)
※Location of air inlet/outlet
 Air inlet/outlet must be located where exhaust gas doesn’t flow in.
 Air inlet/outlet must be separate from areas where toxic gases flow in, including parking lots
 Air inlet/outlet must be installed where external air doesn`t directly flow into the boiler
 Air inlet/outlet must be separate from areas where toxic gases flow in, including parking lots.
 Air inlet/outlet must be installed where external air doesn’t directly flow into the boiler.
Type
Size of Air
Inlet/Outlet/Ventilating
Opening at the
Top(Effective Area)
Gallery
Steel/Plastic
Gallery(Open Ratio0.5)
Wood Gallery
(Open Ratio 0.4)
Boring Gallery
(Open Ratio 0.3)
All types
38.5
77
97
129
23
