APPENDIX A
CONFIGURING AND CALIBRATING YOUR SMARTBOARD E70 INTERACTIVE FLAT PANEL WITH WINDOWS
27 smarttech.com/kb/170534
6. Press enter to skip through any remaining screens until the window closes.
NOTE
Do not touch any further touch screens as the correct association between the selected
monitor and touch screen will be lost.
7. Click OK.
IMPORTANT
If you have difficulty with the above procedure, set up your E70 as the primary monitor (or
main display) and try again. You can switch your main display back to its original setting after
you have successfully identified the E70 as your touch screen.
Calibrating your E70 with Windows 7 or 8
Calibration ensures that your E70 recognizes the position of your pen. In Windows 7, when you
calibrate for the first time, the screen uses 16 different reference points. This initial calibration
applies to all users of the E70. If you calibrate again, only 4 points are used, and apply only to your
user account. http://windows.microsoft.com/en-ca/windows7/getting-more-out-of-your-tablet-pc
Under normal conditions, the SMARTBoard E70 should not require calibration. However,
calibration may be required if touch is inaccurate.
NOTE
Calibration should be done only by an administrator.
To calibrate your SMARTBoard E70:
1. Launch Control Panel -> Tablet and PC Settings. Ensure that the Display tab is visible. Select
E70 from the display drop down menu.
