6 SMART LightRaise Installation and User's Guide
SMART LightRaise Projector Mount Parts
Unpacking the SMART LightRaise Projector Mount
The SMART LightRaise projector mount is shipped in two cartons, unless you have purchased
only one part of the LightRaise projector mount. Open your carton(s) and verify the contents
using these lists:
Console Carton Contents
•
1 console, equipped with Control System and power bar inside the cabinet, a bracket
inside the right door, as well as cables to connect internal and external computer and
VCR or DVD player and a SMART Board interactive whiteboard
•
1 console wall bracket, attached to the back of the console with two security screws
•
1 console accessory kit that includes:
•
drywall installation kit
•
concrete or cinder block installation kit
•
cable cleat bag, which contains 2 cable cleats, 2 nuts and 2 washers
•
other items listed on page 7
•
1 power cable
•
1 box containing the wireless keyboard and IR receiver
Boom Carton Contents
•
1 telescoping boom
•
2 metal wall-mount boom brackets (upper and lower)
•
1 hanger bracket for a SMART Board interactive whiteboard (optional)
•
1 spacer bracket for a SMART Board interactive whiteboard (optional)
•
2 wall-bracket covers
•
4 boom covers
•
1 template tool
•
projector cable bag
•
1 boom accessory kit that includes:
•
drywall installation kit
•
concrete or cinder block installation kit
•
projector mounting kit
•
projector mounting plate
•
other items listed on page 8
NOTE:
If you receive a SMART Board interactive whiteboard at the same time, unpack and
verify the contents using the list included with the board. However, unless you are only
mounting the console of the SMART LightRaise projector mount, do not use the wall bracket
shipped with the board. Instead, mount the board using the hanger bracket included with the
LightRaise projector mount. Follow the instructions in this guide, beginning on page 11.
