8 SMART LightRaise Installation and User's Guide
Boom Hardware Kits
To perform the boom installation, you'll need to use more than one hardware kit. The kit you
use depends on the type of wall onto which you're installing the SMART LightRaise projector
mount.
Use the following chart to determine which kit(s) you need and to verify the kit contents.
Type of Wall Kit Required Kit Contents
Concrete or cinder block Concrete/cinder block
installation kit
•
24 ¼ x 1¾" concrete
anchor screws
•
1
3
/
16
x 3½" masonry drill
bit
Drywall with wooden studs Drywall and wood stud
installation kit
•
12 self-drilling drywall
anchors
•
12 #8 x 1¼" AB truss
head screws
•
12 #8 x 2½" Phillips
round head wood screws
•
12 #8 burr washers
Drywall with metal studs Drywall and metal stud
installation kit
•
12 self-drilling drywall
anchors
•
12 #8 x 1¼" AB truss
head screws
•
12 toggle bolt anchors
•
12 ¼-20 UNC x 1½"
Phillips pan head bolts
To use toggle bolts, you'll need to drill two holes:
•
a ¼"
(6 mm)
pilot hole
•
a final ½"
(13 mm)
hole
NOTE:
When drilling holes in metal studs, where possible hit the center of the stud.
In addition to the installation kits, your boom accessory kit should include:
•
a bag containing the projector mounting hardware specific for your projector, with the
contents of this kit detailed in the instructions provided in the bag
•
6 #10-32 x
5
/
16
" UNF Phillips pan head screws, 2 #10 lock washers, security hex key,
3
/
32
"
ball hex key, 2 hook and loop fasteners, 2 cover concealment labels and the
SMART
LightRaise Projector Mount Supported Projector Reference List
