Appendix D Managing SMARTBoard
MX series displays using RS-232
For SMARTBoard MX series displays
Configuring the serial interface settings 107
Communication structure 107
Power states 110
Commands 111
You can connect a control system or terminal emulation program on your computer to the display's
room control input and remotely select video inputs, change power and sleep states, and get
information about the display’s current settings, such as current input source, contrast and power state.
Connect an RS-232 cable from the control system or the computer’s serial port to the RS-232connector
on the bottom of the display.
Important
Use only a standard RS-232 cable. Do not use a null modem cable. Null modem cables typically have
ends of the same type.
