SMARTFOX Pro 2 - Display: Electrical Data (Voltage, Current, Power); Voltage, Current, Power, and Frequency Display

DISPLAY OF THE MEASURED
VALUES
www.smartfox.at
A N A L O G A N E R G I E = 0
. 0 0 K W H
S P A N N E : A = 2 3 4 V B
= 2 3 5 V , C = 2 3 4 V
P ( W / K W ) : A = - 8 2
W B = 0 . 0 0 W C = 8 0
W
f r e q u e n c e : 5 0 . 1
h Z
Analogue output energy
Analogue output energy = the total energy used by SMARTFOX/analogue output.
Voltage
Voltage A=234V B=235V, C=236V. The measured mains voltage per phase is displayed.
(A=L1, B=L2, C=L3).
Power
Current A= 0.35A B= 0.00A C=0.35A. The measured current per phase is displayed (A=L1,
B=L2, C=L3).
Power
P(W/kW): A=-82W B=0.00W C=80W. The measured power is displayed (A=L1=- 82W,
B=L2=0.00W, C=L3=80W). 82 watts are fed back into the mains on conductor L1.
fe
d back into the mains. 80 watts are drawn from conductor L3. The sum of the 3
conductors gives the total power (Pges = -82W + 0W + 80W =-2W supply to the
mains).
Frequency
Frequency: 50.1Hz, The current mains frequency is displayed. (50.1Hz)
S T R O M : A = 0 . 3 5 A
B = 0 . 0 0 A C = 0 . 3 5
A
