S T R O M W A N D L E R
E X T E R N 0 4 0 : 1
NOTE!
For connection of additional transformer, see page 8.
ATTENTION!
No data is saved if the SD card is not activated.
D A T U M a n d P a g e 2
0 1 8 / 0 6 / 0 6 1 0 : 1 0
Current transformer
When connecting with the supplied standard 80A or 100A converters (RJ12 plug),
1:1 is set here. With additional transformers, you can choose between 2 and 999,
depending on the transformer ratio (e.g. 200:5 transformer results in a ratio of 40:1
200:5=40). Thus, a maximum transformer ratio of 4995A can be achieved with 5A
transformers.
Log Interval Setting
All measured values are written to the SD card at the set log interval. A minimum log
interval of 30s can be set.
Setting Date Time
Setting the date and time.
22
L O G I N T E R V A L
0 3 0 S E C
To Next Page
