ATTENTION!
When connecting the voltage input variable, the assignment to the current
connection is important, i.e. the respective terminal of the voltage connection must
also be located in the outer conductor in which the current transformer is located.
Mechanical strength DIN EN 61010 Part 1
Accuracy, overload air
and creepage distance
connection
DIN EN 60688
DIN EN 61010 Part 1
DIN 43807
Dimensions
[WxHxD]
147mm x 90mm x 58 Width 8TE
Assembly
Top-hat rail mounting. At ambient temperatures of >45°C, however, a distance of
10mm is recommended. The mounting location should be as vibration-free as
possible and must not exceed an ambient temperature of 55°C.
Electrical
Connection
The regulations for the installation of electrical systems must be observed, according to
DIN 43807, via screw connection max. 1.5mm². When installing the current
Whe
n installing the current transformer, the correct current direction K and L must be
observed (K corresponds to the power supply company side, L corresponds to the
system side).
Hedging
DIN EN 61010 Part
1
Housing with protective insulation,
protection class II, for
working voltages up to 600V
(mains to neutral) pollution degree 2,
measurement category CAT III
WARNING!
This unit may only be installed b y a qualified electrician, otherwise there is a risk of
fire or electric shock!
Protection class DIN EN 60529 Housing IP21
Disconnection DIN EN 61010 Part 1, 3, 3KV 50Hz 4s
