SMARTFOX Pro 2 User Manual

SCOPE OF DELIVERY & TECHNICAL
DATA
www.smartfox.at
Rated current 80A | 100A or via additional transformer
4995A
Connection
s
L1/L2/L3/N/PE 3xL 1xN 1xPE 1.5mm²
Relay 1-4 4x 2x1,5mm²
Analogue outputs pluggable Gnd/I+/V+/24VDC1mm²
Converter Pluggable 1xRJ12 6pol.
Communication S0 input | CAN | RS485
Scope of delivery
1x SMARTFOX Pro 2 energy consumption
controller 1x Micro SD Card
1X Current transformer 3-phase up to 80A | 100A
Technical data SMARTFOX Pro
Nominal voltage 3X230V/400V
Nominal frequency 50Hz
Overload continuous
Relay switching
capacity
Voltage max. 265V, current 260A
5A/250VAC |max. resistive
Consumer
Analogue outputs 0-10 VDC | 1-10VDC
0-20mA | 4-20mA
Interfaces WLAN | 100Mbits/s Ethernet LAN
Temperature input PT1000
Voltage range 185-265V
Self-consumption 4W
View
2-line display here the current
values can be read by pressing the
keys.
Surge overload Voltage 1000V 65μs
