SETTINGS - ANALOGUE OUTPUT
U O U T : 0 - 1 0 V
I O U T : 0 - 2 0 M
A
R E G L E R P = 3 0 0 W V E
R = 3
C I E L W E R T = - 0 0 2 0 W
A N A L O G U B E R W . = A I N
U/IOUT
Voltage output - UOUT
Setting of the voltage output. It can be selected between 0-10V & 1-10V. The voltage
output is pre-parameterised to 0-10V by default.
Current output - IOUT
Setting of the current output. You can choose between 4-20mA and 0-20mA. The
current output is already pre-parameterised to 4-20mA.
Controller
behaviour
Set the nominal power of the connected consumer (heating rod) here. The setting
of the nominal power should be very precise, as this value is used as the basis for
the PNUTZ calculation.
The setting BEHAVIOUR specifies how nimble or sluggish the analogue output
reacts. The value can be set between 1 (very fast) and 10 (very slow). By default,
the value is set to 3 (nimble).
Target value
Setting TARGET VALUE between -30000W & +30000W, set the desired value
here to which the system is to be constantly regulated. To avoid drawing energy
from the mains, a negative value should be set here. The standard setting -20W is
very suitable here.
26
ATTENTION! If there is a battery storage in the system, the target value must be
set to at least -200W to avoid charging the heating element from the battery.
Power controller
