HAT700 SERIES ATS CONTROLLER USER MANUAL
HAT700 Series ATS Controller 2018-12-13 Version 1.5 Page 22 of 51
No.
Item
Range
Default
Description
2: PC Two-stage (PC switch without OFF
position)
8
Forced Open Action
(0-1)
0
0: Warn Alarm 1: Fault Alarm
9
Continuously Close
(0-1)
0
0: Disable ; 1: Enable
If “Enable” is selected, “Close Time” and
“Open Time” are deactivated.
10
Sync Enabled
(0-1)
0
0: Disable ; 1: Enable
11
Volt diff. Enabled
(0-1)
0
0: Disable ; 1: Enable
12
Volt diff.
(0-50)V
5
It’s the maximum voltage difference when
the synchronization is successful.
13
Freq diff.
(0-0.50)Hz
0.20
It’s the maximum frequency difference when
the synchronization is successful.
14
Phase diff.
(0-20) °
5
It’s the maximum phase difference when the
synchronization is successful.
15
Fail to Sync Action
(0-1)
0
0: Warn Alarm 1: Fault Alarm
If the Fail to Sync” failure occurs, “Sync
Waiting” signal will output continuously until
the synchronization is successful.
When the Warn Alarm” is selected, the
alarm will be removed after the
synchronization is successful or exit.
When the “Fault Alarm” is selected, the
alarm will be removed only when the “Reset”
button is pressed.
16
Transfer in Sync Fail
(0-1)
0
0: Disable ; 1: Enable
If the “Fail to Sync” failure occurs, the alarm
will NOT be initiated and “non-sync close”
will be initiated.
17
Fail to Sync Delay
(0-9999)s
120
“Fail to Sync”alarm will be initiated after the
delay has expired.
18
Breaker Feedback
Time
(0.1-1.0)s
0.6
When the input is active, its delay time will
be initiated. If the correct signal is detected
before the delay has expired, pulse output
will be terminated; If the correct signal is
NOT detected after the delay has expired,
“Fail to Close” or “Fail to Open” alarm will be
initiated.
19
ATS Power Type
(0-1)
1
0: DC Power1: AC Power
20
ATS Power Low Point
(0-100)%
70
Lower limit voltage of switch power; The
switch can not transfer when the value has
fallen below the set value.
21
ATS Power High Point
(0-200)%
130
Upper limit voltage of switch power; The
switch can not transfer when the value has
exceeded the set value.
Generator Setting
1
Gen Start Delay
(0-9999)s
1
When the genset is ready to start, start
