HAT700 SERIES ATS CONTROLLER USER MANUAL
HAT700 Series ATS Controller 2018-12-13 Version 1.5 Page 23 of 51
No.
Item
Range
Default
Description
delay begins, after the start delay has
expired, start signal will be initiated.
2
Gen Stop Delay
(0-9999)s
5
When the genset is ready to stop, stop delay
begins, after the stop delay has expired,
stop signal will be initiated.
3
Gen-Gen Start Mode
(0-2)
0
0: Cycles Gens
1: Master-Slave Gens
2: Balance Gens Hours
3: Not Used
4
S1 Cycles Work Time
(0-9999)min
720
Gens cycle start S1 running time.
5
S2 Cycles Work Time
(0-9999)min
720
Gens cycle start S2 running time.
6
Genset Available Time
(0-9999)s
120
When the start signal is active, the start
delay will be initiated. If the gen voltage lasts
abnormal after the delay has expired,
“Genset Fault” alarm will be initiated.
7
Battery Volt Enable
(0-1)
0
0: Disable ; 1: Enable
8
Battery LV Warn
(0-1)
0
0: Disable ; 1: Enable
9
Battery Under Volt Set
Value
(0-100.0)V
10.0
“Battery Under Volts” alarm will be initiated if
the battery voltage has fallen below the set
value.
10
Battery Under Volt
Return Value
(0-100.0)V
10.5
“Battery Under Volts” alarm will be removed
if the battery voltage has exceeded the set
value.
11
Battery Under Volt
Delay
(0-3600)s
60
If the battery voltage has fallen below the set
value, “Battery Under Volts” alarm will be
initiated after the delay has expired.
12
Battery OV Warn
(0-1)
0
0: Disable ; 1: Enable
13
Battery Over Volt Set
Value
(0-100.0)V
30.0
“Battery Over Volts” alarm will be initiated if
the battery voltage has exceeded the set
value.
14
Battery Over Volt
Return Value
(0-100.0)V
29.5
“Battery Over Volts” alarm will be removed if
the battery voltage has fallen below the set
value.
15
Battery Over Volt
Delay
(0-3600)s
60
If the battery voltage has exceeded the set
value, “Battery Over Volts” alarm will be
initiated after the delay has expired.
Scheduler Config
1
Schedule Gen Enable
(0-1)
0
0: Disable ; 1: Enable
2
Schedule Load
(0-1)
0
0: Off Load
1: On Load
3
Schedule Period
(0-2)
0
0: Monthly
1: Weekly
2: Daily
4
Schedule Monthly
(1-31)
1
The date of start the genset
5
Schedule Weekly
(1-127)
1
Bit0: Sunday
Bit1: Monday
